[back] Deep (Ha- and OIII)-Image of M 57 (Ring Nebula) with IC 1296 and others in Lyra [NED]
Higher resolved image / höher aufgelöstes Bild (1800 x1448 Pixel)
(c) 2009 All astro photo images are copyrighted. They may not be used or reproduced without explicit written permission from the authors. |
|
3' |
|
About this Image / Über dieses Bild
CCD: | SBIG STL-11000M |
Image Type, Orientation: | (L+Ha)-(R+Ha)-(G+OIII)-(B+OIII)-Composite, North is at 12:00h |
Exposure time: | L: 9x900 sec. + 12x600 sec., Ha: 7x900 sec., OIII: 12x900 sec., R,G,B: 4x900 sec. + 6x600 sec., all 1x1 bin (15h total) |
Exposure date: | August 23rd, 2006 and some nights in 2008 |
Location: | Skinakas Observatory at Crete, Greece |
Filter: | SBIG 2" LRGB filter set for STL and Astronomik Typ II Ha OIII filter |
Instrument: | Ganymed 60cm-Hypergraph in secondary focus (f=4938.3 mm), partial remote controlled from Weisenheim am Berg and Sörth/Germany |
Seeing (FWHM): | 1.2" |
Photographer: | Volker Wendel, Josef Pöpsel, Bernd Koch, Stefan Binnewies, Rainer Sparenberg |
Remarks: |
The image above is the result of 15 hours exposure time with Ganymed at Crete. The main part of image editing was done by Volker Wendel and Stefan Binnewies. An image composed only by the 600sec. L-RGB data of the image above (and some extra infos) can be found below. |
Bemerkungen: |
Dieses Bild ist das Ergebnis von insgesamt 15 Std. Belichtungszeit mit Ganymed auf Kreta. Die Hauptarbeit der Bildbearbeitung trugen Volker Wendel und Stefan Binnewies. Ein Bild, das lediglich die 600. sec. L-RGB Daten des Bildes oben verwendet (sowie einige Extra-Infos) sind anschließend zu finden. |
L-RGB Image of M 57[NED]
Higher resolved image / höher aufgelöstes Bild (2000 x1656 Pixel)
(c) 2006 All astro photo images are copyrighted. They may not be used or reproduced without explicit written permission from the authors. |
|
2' |
|
About this Image / Über dieses Bild
CCD: | SBIG STL-11000M |
Image Type, Orientation: | L-RGB Composite, North is at 11:45h |
Exposure time: | L:6x600 sec. 1x1 bin, R,G,B:4x600 sec. 1x1 bin |
Exposure date: | August 23rd, 2006 |
Location: | Skinakas Observatory at Crete, Greece |
Filter: | SBIG 2" LRGB filter set for STL |
Instrument: | Ganymed 60cm-Hypergraph in secondary focus (f=4938.3 mm) |
Seeing (FWHM): | 1.2" |
Photographer: | Stefan Binnewies, Josef Pöpsel, Rainer Sparenberg |
Remarks: |
A 200%-Version of M 57 based on the R,G,B-exposures of this image can be found here. Since the ring of M 57 is much brighter than the rest of the image, it was processed seperatly and combined with the rest of the image afterwords. A wide field image of the area around M57, which was photographed in parallel with a piggybacked Takahashi FSQ and a Canon 20D can be found here. CCDSharp and DDP were used. |
Bemerkungen: |
Eine 200%-Version von M 57, die auf den R,G,B-Aufnahmen dieses Bildes beruht, befindet sich hier. Da der Ring von M57 viel heller als der Rest des Bildes ist, wurde er separat bearbeitet und erst anschließend mit dem Rest des Bildes kombiniert. Eine Wide-Filed-Aufnahme der Gegend um M57, die parallel zu diesem Bild mit einem huckepack montiertem Takahashi FSQ und einer Canon 20D entstand, befindet sich hier. CCDSharp und DDP wurden benutzt. |
