[back] NGC 5139 (Omega Centauri) in Centaurus[NED]
Higher resolved image / höher aufgelöstes Bild (1800 x1746)
Concentration Class VIII. |
|
5' |
|
(c) 2005 All astro photo images are copyrighted. They may not be used or reproduced without explicit written permission from the authors.
About this Image / Über dieses Bilde
CCD: |
ST10 XME for the center of the image and Fleischman 7kx4k for the outer area |
|
Image Type, Orientation: |
LRGB Composite, North is at 12:00h |
|
Exposure time: |
For the ST10 image: For the 7kx4k image: |
L: 20x 5s 1x1 bin, R,G,B: 20x 5 sec.each, 2x2 bin L: 6x120s 1x1 bin, R,G,B: 2x120 sec.each, 2x2 bin |
Exposure date: |
May 8th, 2004 (ST10) and May 5th, 2005 (7kx4k) |
|
Location: |
Capella Observatory at Amani Lodge, Kupferberg near Windhoek, Namibia |
|
Filter: |
FR03 + Astronomik "Self made" filter slider with Astronomik |
|
Instrument: |
Ganymed 60cm-Hypergraph in secondary focus, f=4800 mm |
|
Seeing (FWHM): |
1.9" for the ST10 image, 2.5" for the 7kx4k image |
|
Photographer: |
R. Sparenberg, S. Binnewies, V. Robering for ST10 image, Josef Pöpsel, Beate Behle for 7kx4k image |
|
Remarks: |
The image above shows (at least in parts) one of the first images, shot with a not very common CCD-camera. This is a 7kx4k CCD camera from OES with a resolution of 7x1024 x 4x1024 pixels, which means 28 (!) mega pixels in total. Each of these pixels has a dimension of 12µ² resulting in an active area which is as big as the biggest side of a cigarette box. The filter slider for this camera is a self made version which proofed best. Unfortunately the efficiency of the chip (which originally was produced for the use in medical devices) lacked far behind our expectations. Some QE diagrams showed that the QE of the chip was more or less comparable to a SBIG STL 11000, but this did not turn out to be correct - the efficiency of the chip is only about ⅓ of the STL 11000 and as a result not very useful for deep sky imaging. For the central part of the image above a "normal" image of a ST10 was used (see image below), which was done nearly exact one year before. The reason was the moderate seeing in may 2005, which was "jazed up" a bit in this way. Image processed with CCDSharp and DDP.
|
|
Bemerkungen:
|
Das Bild oben zeigt (zumindest in Teilen) eine der ersten Aufnahmen, die mit einer etwas außergewöhnlichen CCD-Kamera gemacht wurden. Es handelt sich hierbei um die CCD-Kamera 7kx4k der Firma OES mit einer Auflösung von 7x1024 x 4x1024 Pixel, also insgesamt 28 (!) Megapixel. Jedes dieser Pixel ist 12µ² groß, sodass die gesamte aktive Fläche etwa das Format der großen Fläche einer Zigarettenschachtel hat. Der hierzu nötige Filterschieber entstand in Heimarbeit und hat sich bestens bewährt. Die Effizienz des Chips (der ursprünglich für den Einsatz in der Medizintechnik entwickelt wurde) blieballerdings weit hinter unseren Erwartungen zurück. Entsprechende Diagramme ließen vermuten, dass sie vergleichbar mit der einer STL 11000 von SBIG ist, was sich aber leider nicht bestätigte - sie ist nur ca. ⅓ so empfindlich und somit für Deep-Sky-Aufnahmen leider recht ungeeignet. Für den zentralen Teil des Bildes oben wurde eine "normale" Aufnahme mit der ST10 verwendet (siehe Bild unten), die ziemlich genau ein Jahr zuvor entstand. Der Grund war das mäßige Seeing im Mai 2005, das so ein wenig "aufgepeppt" werden konnte. Das Bild wurde mit Hilfe von CCDSharp und DDP bearbeitet. |
Central Part of NGC 5139
Concentration Class VIII. |
|
60" |
|
(c) 2004 All astro photo images are copyrighted. They may not be used or reproduced without explicit written permission from the authors.
