[back] M 15 in Pegasus [NED]

Higher resolved image / höher aufgelöstes Bild   (2000 x1333 Pixel)

Concentration Class IV

(c) 2006 This astro photo images is copyrighted. It may not be used or reproduced without explicit written permission from the authors and Stefan Heutz.

About this Image / Über dieses Bild

CCD: SBIG STL-11000M
Image Type, Orientation: RGB Composite, North is at 12:15h
Exposure time: R,G,B :4x300 sec. 1x1 bin
Exposure date: August 26th, 2006
Location: Skinakas Observatory at Crete, Greece
Filter: SBIG 2" LRGB filter set for STL
Instrument: Ganymed 60cm-Hypergraph in secondary focus (f=4938.3 mm)
Seeing (FWHM): 1.2"
Photographer: Stefan Binnewies, Josef Pöpsel, Rainer Sparenberg, image editing by Stefan Heutz.


Remarks:

M15 is one of the rare globular clusters which contains a planetary nebula. The PN is called Pease1, has a visual diameter of <3" and is located in upper left direction near to the center of M15 (see here). The image below shows the area around Pease1 in a 600% scaled version. To be honest: without kowing about the existence and position of Pease 1, we would not have detected the PN near the crowded center of M15. May be well take a new try if seeing is ~0.5"...

We expected a dim red HII-Region around Pease1, but even hard color scalings did not show it - at least in our raw data Pease1 is simply turquoise blue. May be, its central star outshines the rest of the PN.

Another interesting detail is a galaxy cluster shining through M15. It is located in the middle of the center of M15 and the bright white star in the lower left part of the image.

LR-Sharpening and DDP were used.



Bemerkungen:

M15 ist einer der wenigen Kugelsternhaufen, die einen Planetarischen Nebel enthalten. Der PN heißt Pease1, hat einen visuellen Durchmesser von <3" und befinde sich links oberhalb des Zentrums von M15 (siehe hier). Das Bild unten zeigt die Gegend um Pease1 in einer 600%-Vergrößerung. Um ehrlich zu sein: ohne zu wissen, dass und wo Pease1 existiert, hätten wir ihn nicht inmitten des Stern-Gewusels nahe dem Zentrum von M15 entdeckt.

Wir haben einen leicht rote HII-Region um Pease1 erwartete, aber selbst intensives Farb-Skalierung hat nichts dergleichen gezeig - zumindest in unseren Rohdaten ist Pease1 einfach türkis blau. Mag sein, dass sein Zentralstern den Rest des PNs überstrahlt.

Ein weiteres interessantes Detail ist ein Galaxien-Clsuter, das durch M15 scheint. Es befindet sich in der Mitte zwischen dem Zentrum von M15 und dem hellen weißen Stern im unteren linken Teil des Bildschirms.

LR-Schärfung und DDP wurden benutzt.





(c) 2006 This astro photo images is copyrighted. It may not be used or reproduced without explicit written permission from the authors and Stefan Heutz.

600%-Version of M15 around Pease1 (compare this with the HST-image) / 600%-Version von M15 um Pease1 herum. (Vergleiche HST-Bild)
